價格：人民幣11.5萬-12.6萬
| Performance | 1 | 額定載重量rated loading | 3000kg |
| 2 | 整機重量overall weight | 9100-9600kg | |
| 3 | 斗容量bucket capacity | 1.53-2.5m3 | |
| 4 | zui大牽引力maximum tractionforce | 97KN | |
| 5 | zui大掘起力 maximumbreakout force | 120KN | |
| 6 | zui大爬坡能力maximum grade ability | 30℃ | |
| 7 | zui大卸載高度maximum dump height | 3200mm | |
| 8 | zui大卸載距離maximum dump reach | 1006mm | |
| 9 | 整機外形尺寸overall dimension (L×W×H) | 7200*2430*3070 | |
| 10 | zui小轉彎半徑minimum turning radius | 5097mm | |
| 發動機Engine | 11 | 型號model | 道依茨WP6G125E332 |
| 12 | 型式type | 高壓共軌國三 | |
| 13 | 汽缸數-缸徑*行程NO. of cylinder-bore*stroke | 6-108*125 | |
| 14 | 額定功率rated power | 92kw—2200r/min | |
| 15 | zui大扭矩maximum torque | 500N.m | |
| 16 | zui低燃油消耗率 min. fuel-consume ratio | ≦210Kw h | |
| 傳動系統 Transmission system | 17 | 變矩器型式torque converter | YJ315-X |
| 18 | 變速箱型式gearbox mode | 定軸常嚙合式 Power shaft normally engaged straight gear | |
| 19 | 檔位數gears | 前進檔4個，倒退檔2個 4forward 2 reverse | |
| 20 | zui高車速maximum speed | 39km/h | |
| 驅動橋Drive axles | 21 | 主減速式：main reducing spiral | 螺旋傘齒輪一級減速bevel gear grade 1reduction |
| 22 | 輪邊減速型式decelerating mode | 一級行星減速 Planetary reduction grade 1 | |
| 23 | 軸距wheel base (mm) | 2630mm | |
| 24 | 輪距wheel tread | 1200mm | |
| 25 | zui小離地間隙ground clearance | 400mm | |
| 液壓系統 Hydraulic system | 26 | 系統工作壓力system working pressure | 16,5MPa |
| 27 | 動臂提升時間boom lifting time | 4.6 | |
| 28 | 三項和total time | 8.2±0.5s | |
| 制動系統 Brake system | 31 | 行車制動service brake | 氣頂油鉗盤式四輪制動 air assist disc brake on 4 wheels |
| 32 | 駐車制動parking brake | 手動嵌盤式 Manual disk brake | |
| 輪胎 Tyre | 33 | 規格type specification | 17.5-25 |
| 34 | 前輪氣壓front tyre pressure | 0.4Mpa | |
| 35 | 后輪氣壓rear tyre pressure | 0.35Mpa |
